N9K-C93120TX is the Nexus 9300 with 96p 100M/1/10G-T and 6p 40G QSFP. The Cisco Nexus 9300 platform consists of fixed-port switches designed for top-of-rack (ToR) and middle-of-row (MoR) deployment in data centers that support enterprise applications, service provider hosting, and cloud computing environments. They are Layer 2 and 3 nonblocking 10 and 40 Gigabit Ethernet switches with up to 2.56 terabits per second (Tbps) of internal bandwidth.
N9K-C93120TX Specification |
|
| Ports | 96 fixed 1/10GBASE-T and 6 QSFP+ ports |
| Supported speeds | 100 Megabit Ethernet and 1/10 Gigabit Ethernet speeds |
| 40 Gigabit Ethernet uplink ports | 6 fixed QSFP+ ports |
| Advanced QSFP+ optics enable connectivity using existing 10 Gigabit Ethernet fiber.
The switch offers 25 MB of additional packet buffer space shared with all ports for more resilient operations. |
|
| Power supplies (up to 2) | 1200W AC, 930W DC, or 1200W HVAC/HVDC |
| Typical power (AC) | 542W |
| Maximum power (AC) | 948W |
| Input voltage (AC) | 100 to 240V
*PSU redundancy is not supported when used in 110V |
| Input voltage (HVAC) | 200 to 277V |
| Input voltage (DC) | -40V to -72V DC (min-max)
-48V to -60V DC (nominal) |
| Input voltage (HVDC) | –240 to –380V |
| Frequency (AC) | 50 to 60 Hz |
| Fans | 2 |
| Physical (H x W x D) | 3.5 x 17.5 x 22.5 in. (8.9 x 44.5 x 57.1 cm) |
| RoHS compliance | Yes |
| Weight | 26 lb (11.8 kg) (without power supplies, fans, or uplink module) |
